Start with the site
Rear wheels, a transport handle and a folding support for floor placement and storage.
MOBILE DISPLAY SYSTEMS / SINGLE FACE
43-Inch Portable Battery-Powered Digital Signage
43-inch battery-powered signage with rear wheels and a folding stand.
- Screen
- 43-inch IPS LCD
- Format
- Single-sided · Portrait
- Battery
- 24 V / 78 Ah LiFePO4
- Net weight
- 48.25 kg · listed
Unit price
$1,801.00 USD
43-inch · Android · Non-touch
Final pricing depends on configuration and quantity.
01 / PRODUCT LOGIC
Move your message.
Bring menus, promotions and visitor information to the right location. Battery power and a folding support make this portrait display easy to position.
Check the screen
43-inch portrait IPS LCD with tempered anti-glare glass.
Specify the workflow
USB playback, Wi-Fi and Ethernet connections. Discuss your CMS and remote publishing requirements.
Product features
Movement and dimensions
02 / TECHNICAL RECORD
Technical specifications
Choose the hardware configuration for your project.
Display
| Screen | 43-inch IPS LCD; single-sided portrait |
|---|---|
| Resolution | 1920 × 1080 native panel; 1080 × 1920 portrait canvas |
| Brightness | Up to 2,000 cd/m² listed; 700–2,000 cd/m² automatic adjustment |
| Glass / touch | Tempered anti-glare glass; non-touch selection |
Player and power
| Platform | Android; final OS version and RK3576 board to be specified |
|---|---|
| Memory / storage | 4 / 8 GB RAM; 32 / 64 / 128 GB eMMC options |
| Content transfer | USB, Wi-Fi, RJ45; CMS and cellular scope configured separately |
| Battery | 24 V / 78 Ah LiFePO4 reference |
| Charging | 100–240 V AC input; approximately 7 hours listed recharge time |
Mechanical and site requirements
| Placement | Floor standing; rear wheels and folding support |
|---|---|
| Net weight | 48.25 kg listed |
| Housing / placement dimensions | 584 × 1235 mm housing; 1245.8 mm overall height; 485 mm open depth; 205 mm folded depth |
| Packed dimensions | 139 × 33.5 × 70.5 cm |
| Gross weight | 57 kg |
Configuration notes
Final specifications, software and delivery are confirmed in your quotation.
- Approved dimensional drawing
- Gross weight and package measurements
- Certified operating temperature and humidity
- Product-specific IP/enclosure rating
- Product-specific compliance evidence
- Warranty terms for selected build
- Manufacturing and shipping lead time
- Verified runtime at target brightness
Detailed specification references
03 / SYSTEM INTEGRATION
Connect your content.
USB playback, Wi-Fi and Ethernet connections. Discuss your CMS and remote publishing requirements.
Content delivery
Confirm media format, scheduling, local playback and update procedures for the selected player.
Network & security
Review ports, Wi-Fi, LAN, firewall policy, access control and provisioning with the IT team.
CMS / APK / POS interface
Share your CMS, app or POS requirements for a configuration review.
Acceptance requirements
Share a test plan and desired documents early to define project scope and validation responsibilities.
Content and system options
04 / SITE READINESS
From product photo to installation plan.
Before quoting the final build, align the physical location, operating profile and owner of each integration requirement.
- Ground conditions, traffic path and stability
- Brightness target and exposure to sunlight
- Operating duration, charging access and power policy
- Content source, CMS version and network permissions
- Service clearance and transportation route
- Drawing, packaging and compliance documents
Application illustrations
Project requirements
05 / COMMERCIAL SCOPE
Configure your project.
Tell us your quantity, destination and requirements.
UNIT PRICE
$1,801.00 USD
43-inch / Android / Non-touch
- Reference scope43-inch · Android · Non-touch
- ConfigurationConfirm the display, processor, memory, interfaces, power and accessories included in the ordered unit.
- CMS & softwareChoose hardware-only or discuss the required software and licensing.
- DocumentationRequest drawings, compliance documents and warranty terms for your configuration.
- Order termsFinal unit price, quantity, freight, payment and lead time are supplied in the sales quotation.
About Gemdragon
06 / PROJECT QUESTIONS
Common questions before quotation.
Can this display run without a power cable at the placement point?
The reference model lists a 24 V / 78 Ah LiFePO4 battery. Actual runtime, charging conditions and operating profile have not been verified; share your expected hours and content schedule when requesting a quote.
Is 2,000 nits the guaranteed brightness?
No. The source lists up to 2,000 cd/m² and an automatic range of 700–2,000 cd/m². Confirm the selected panel, measurement conditions and expected installation light level.
Which Android version and CMS are supported?
Android is listed, but the exact OS build and player board remain to be specified. Supply your APK, CMS and network requirements for compatibility review.
Can it be used outdoors?
The supplier artwork lists IP65 and operating limits. Request model-specific enclosure documentation and confirm the installation conditions before approving an outdoor deployment.
What is the battery runtime?
The supplier artwork lists 25–30 hours, depending on playback content. Confirm runtime at your required brightness, duty cycle and temperature for the selected battery configuration.
Where can I get the dimensional drawing and certificates?
The supplier dimension drawing is included on this page. Request the approved revision and product-specific compliance documents for your ordered configuration.
07 / START A PROJECT
Get a quote shaped around your site.
Tell us the quantity, installation setting and software you plan to use. Send your request directly to Gemdragon below.
Request a Quote
Fields marked * are required. Company and phone / WhatsApp are optional.
Your selected product
43-Inch Portable Battery-Powered Digital Signage · Selected configuration: 43-inch / Android / Non-touch · $1,801.00 USD per unit; final quotation required.
Include your estimated quantity, delivery country, application, software or CMS, and target delivery date in Project requirements. Read our Privacy Policy.
